STAY 50NB & TIMBER POST FITTING KIT ROTECH TSK50

The Staytight Timber Post Stay Kit TSK50 is a complete end-assembly solution designed for installing fence stays on large timber strainer posts. It uses a tension cable system instead of a rigid rod, making installation faster and easier while maintaining high strength and durability. The kit is suitable for rural and agricultural fencing applications where strong fence tension and long-term stability are required. No welding is required during installation.

FEATURES & BENEFITS
Heavy-duty 50NB stay pipe provides strong structural support capable of handling high fence tension loads.
Designed specifically for large timber posts with diameters greater than 250 mm, ensuring compatibility with heavy strainer posts.
Complete kit includes all required components, reducing installation time and eliminating the need to source additional parts.
No welding required, allowing faster and safer on-site installation using basic tools only.
Adjustable tension cable system allows installation even when posts are not perfectly aligned or when ground conditions are uneven.
Corrosion-resistant materials, including galvanised and stainless-steel components, provide long service life in harsh outdoor environments.
Floating footplate helps transfer fence load into the post, reducing post movement and improving long-term fence stability.
Designed for fast installation, typically taking around 10 minutes per assembly.

SPECIFICATIONS
Product Name: Staytight Timber Post Stay Kit
Manufacturer: Rotech Gate Hardware
Part Number: TSK50
Recommended Timber Post Diameter: Over 250 mm
Stay Size: 50NB
Stay Outside Diameter: Approximately 60 mm
Stay Wall Thickness: 2.3 mm
Stay Length: 3250 mm
Fence Height Suitability: Approximately 1200 mm to 2000 mm
Finish: Galvanised and stainless-steel components
Installation Type: Bolt-on system, no welding required

INCLUDED COMPONENTS
50NB stay pipe
Stay connector
Tension cable assembly with double-ended eyebolts
Footplate

APPLICATIONS
Rural and agricultural fencing end assemblies
Timber strainer post support systems
Livestock fencing requiring high tension strength
Farm boundary and paddock fencing
Fence installations in uneven, rocky, or sloping terrain
